Features / Specifications
- Recessed mount
- Surface Mount Brackets Available
- Low profile slimline design
- ADR/ECE approved
- IP67 100% Water proof
- 12 Volt or 24 Volt
- 237mm x 25mm x 3mm
- 5 Year Warranty
Fitting Instructions
Recessed - Mount onto flat surface horizontally. Push lamp and grommet into cutout (cut out 203mm x 19mm) in mounting surface, run wires through back and fix with screws (Max Torque - 8kgf/cm). Products can also be mounted using surface mounting brackets sold separately. Please refer to ADR 13/00 for mounting instructions.
