Features / Specifications
- Recessed Fitting
- Surface Mount Brackets Available
- Low profile slimline design
- ECE Approved
- IP67 100% Waterproof
- 12 Volt Only
- 237mm x 25mm x 3mm
- 5 Year Warranty
Fitting Instructions
Recessed - Mount onto flat surface horizontally. Push lamp and grommet into cutout (cut out 203mm x 19mm) in the mounting surface, run wires through the back and fix with screws (Max Torque - 8kgf/cm). Products can also be mounted using surface mounting brackets sold separately. Please refer to ADR 13/00 for mounting instructions.
