The Dometic Ibis 4 makes improvements on many of the industry-leading features of the highly sought-after Ibis 3 and packages them in a more lightweight roof top unit. The new-generation compressor with inverter technology used in the Dometic Ibis 4 ensures that vibration is minimised, creating a more pleasant environment.
ENERGY EFFICIENT | EVEN AIR DISTRIBUTION | ADJUSTABLE VENTS | QUIET OPERATION
The Dometic Ibis 4 sets a new standard for air conditioning in the mobile living market thanks to several refinements made from the acclaimed Ibis 3.
The Dometic Ibis 4 features a powerful dual-cylinder horizontal compressor, a first for the RV industry, which creates a more balanced roof top unit and reduces the level of vibration. In addition to this, the quiet environment that the Ibis 3 achieved has been replicated. The internal ADB has been redesigned, optimising airflow inside the vehicle. For the first time in an Ibis air conditioner, a turbo-mode fan speed has been included, which allows for rapid cooling inside the RV.
FEATURES:
Automatic Display Brightness: Ambient light sensor automatically adjusts brightness of display
Auto Mode: Set temperature & system will decide mode and fan speed
Sleep Mode: Sleep mode reduces fan speed and compressor speed for reduced noise
Direct Mode Selection: Key modes are at your finger-tips
Turbo Fan Speed:Higher fan speed for faster cooldown
Compressor Type:New Generation Variable Speed Compressor
LIN-BUS/CI-BUS:Connectivity with CI-BUS compatible control panels
Optimised Airflow: Increased efficiency and reduced noise
Low Fan Noise: 3 Standard Speeds (Less fan noise than IBIS3)
Low Profile ADB: 48mm height
2 Piece ADB: Simplified assembly due to reduced number of ADB parts
Dual Cylinder Inverter Compressor: Reduced vibration highly effective
SPECIFICATIONS
SKU number:9600009482
Model: IBIS4 Roof Top + ADB
Model on label: IB36HX01RI & CL01HR001
Scope of delivery: Roof Top Unit, ADB, Remote Control, Installation Material, Installation Manual, Operation Manual
Product Description: Roof air conditioner
Dimensions (Depth x Height x Width):1112 x230 x758 mm
Net weight:40 kg
Roof Opening Fitment:400x400mm or 360mmx360mm (universal)
Input voltage (AC):220-240 V
Input frequency:50 Hz
Cooling capacity (ISO 5151):2625 W
Heating capacity (ISO 5151):3017 W
Power consumption - Cooling mode (ISO 5151):1656 W
Power consumption - Heat pump (ISO 5151) - Display:1560 W
Shipping Dimensions (Depth x Height x Width): 1144 x 366 x 784 mm, 43kg
