SM8 SERIES LED MARKER - CLEAR, RED, AMBER
Description
The new SM8 LED Series markers are designed for the direct replacement of it's existing incandescent models. The SM8 series is made for heavy duty use which features a high impact acrylic lens and strong ABS base, and is suited to OEM and commercial vehicle applications.
Perfect for upgrading existing incandescent versions to LED.
Features
• 9-33 Volt DC integrated circuitry
• Clip mount
• Retro-fit same incandescent style lamp series
• 0.5m Cable
• Fully ADR compliant
| FM8CLED | SM8 Series LED front clearance marker (Clear) - 9-33V |
| SM8ALED | SM8 Series LED side marker (Amber) - 9-33V |
| RM8RLED | SM8 Series LED rear position marker (Red) - 9-33V |
Specifications
| Applications | • Caravans • Trailers • Boat trailers • Light trucks |
| Voltage | 9-33V DC Varivolt® |
| Functions | Front Clearance Marker: Clear Side Marker: Amber Rear Position Marker: Red |
| Wattage | 0.8W - all functions |
| Mounting |
Clip mount |
| Materials |
High impact acrylic lens |
| Environmental |
IP67 Hermetically Sealed |
| Cable Length | 0.5M Standard |
| Dimensions | 90x50x22mm |
| ADR Compliance |
Front Clearance Marker: 49/01, Reflector 47/00 Side Marker: 45/01, Reflector 47/00 Rear Position Marker: 49/00, Reflector 47/00 |
| Homologation Certification |
E-Mark |
| CRN |
Pending |
